Estimating And Costing MCQ's Test No 04

Estimating And Costing MCQ's Test No 04

1 Pick up the incorrect statement regarding a master trap from the following: ?

A) It is provided in between the lower end of the house drain and the street sewer
B) It is provided a cleaning eye at the top of the trap
C) The mica flap valve which opens inwards only, is fitted at the top of the inlet pipe
D) The water seal is less than that of ordinary traps

... Answer is D )
Pick up the incorrect statement regarding a master trap from the following is " The water seal is less than that of ordinary traps "

2 The order of booking dimensions is ?

A) Length, breadth, height
B) Breadth, length, height
C) Height, breadth, length
D) All the above

... Answer is A )
The order of booking dimensions is " Length, breadth, height "

3 The detention period in a septic tank is assumed ?

A) 20 minutes
B) 25 minutes
C) 30 minutes
D) 35 minutes

... Answer is C )
The detention period in a septic tank is assumed “30 minutes"

4 height of the embankment at zero chainage is 0.5 m, the width is 11 m and side slopes 2:1. If the falling gradient of the embankment is 1 in 150, the quantity of the earthwork calculated by Prismoidal formula is?

A) 3250 m3
B) 3225 m3
C) 3250 m3
D) 3275 m3

... Answer is B )
height of the embankment at zero chainage is 0.5 m, the width is 11 m and side slopes 2:1. If the falling gradient of the embankment is 1 in 150, the quantity of the earthwork calculated by Prismoidal formula, is " 3225 m3 "

5 Pick up the item of work not included in the plinth area estimate ?

A) Wall thickness
B) Room area
C) W.C. area
D) Courtyard area

... Answer is D )
Pick up the item of work not included in the plinth area estimate is " Courtyard area "

6 The minimum width of a septic tank is taken

A) 65 cm
B) 70 cm
C) 75 cm
D) 85 cm

... Answer is C )
The minimum width of a septic tank is taken " 75 cm "

7 The diameter of a domestic sewer pipe laid at gradient 1 in 100 is recommended, is ?

A 100 mm
B) 150 mm
C) 200 mm
D) 250 mm

... Answer is B )
The diameter of a domestic sewer pipe laid at gradient 1 in 100 is recommended “150 mm "

8 Pick up the item whose weight is added to the weight of respective item, is ?

A) Cleats
B) Brackets
C) Bolts
D) All the above

... Answer is D )
Pick up the item whose weight is added to the weight of respective item, is " All the above "

9 The unit of measurement is per quintal for the following: ?

A) Collapsible gates with rails
B) Rolling shutters
C) M.S. reinforcement of R.C.C. works
D Expanded metal wire netting

... Answer is C )
The expected out turn for earth work in excavation in ordinary soil per workman per day is ” M.S. reinforcement of R.C.C. works "

10 Pick up the incorrect statement from the following: ?

A) The built up covered area at the floor level of any storey of a building is called plinth area
B) The usable covered area of the rooms of any storey of a building is called carpet area
C) The carpet area of a building along with area of its kitchen, pantry, store, lavatory, bath room and glazed veranda, is called floor area
D) None of these

... Answer is D )
Pick up the incorrect statement from the following is “ None of these "
